54448.3LOS2-CPR | INFRALAN
Fibre optic cable, singlemode 9/125 µm, fibers: 48, G657A1, LSZH, black, 54448.3LOS2-CPR
Order No.: 26P1179
EAN: 4049759235529
MPN:
54448.3LOS2-CPR
Unit Price (€ / mtr.)
4.1769 € *
Available: 0 mtr.
Available in 5 Days: 1,000 mtr.
Leadtime: On Request **
Fiber optic cable, 54448.3LOS2-CPR, INFRALAN
The 54448.3LOS2-CPR is a universale cable for fixed installation indoor and outdoor in cable ducts, tubes and interconnections. Mechanical installation by winch is permitted only when using force meters with recording function. It is not suitable for underground laying (direct buried).
Technical specifications
| Anzahl der Fasern | 48 | |
| Außendurchmesser | 11.2 mm | |
| Farbe | schwarz | |
| Faserart | Singlemode 9/125 µm | |
| Halogenfrei | Yes | |
| Kategorie | G657.A1 | |
| Material | LSZH | |
| Temperaturbereich (bewegt) | -40 °C bis 80 °C | |
| Temperaturbereich (unbewegt) | -5 °C bis 60 °C |
Download
Logistics
| Zolltarifnummer | 85447000 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
