54524.2L-CPR | INFRALAN
FO cable, multimode 50/125 µm, fibers: 24, OM4, LSZH, black, 54524.2L-CPR
Order No.: 26P1495
EAN: 4049759180676
MPN:
54524.2L-CPR
Unit Price (€ / mtr.)
5.1408 € *
Available: 0 mtr.
Available in 5 Days: 1,000 mtr.
Leadtime: On Request **
FO cable, 54524.2L-CPR, INFRALAN
The 54524.2L-CPR is a universale cable suitable for connector assembly, fixed installation indoor and outdoor in cable ducts, tubes and interconnections. Mechanical installation by winch is permitted only when using force meters with recording function Not suitable for underground laying (direct buried).
Technical specifications
| Anzahl der Fasern | 24 | |
| Außendurchmesser | 7.5 mm | |
| Farbe | schwarz | |
| Faserart | Multimode 50/125 µm | |
| Halogenfrei | Yes | |
| Kategorie | OM4 | |
| Material | LSZH | |
| Temperaturbereich (bewegt) | -25 °C bis 70 °C | |
| Temperaturbereich (unbewegt) | -20 °C bis 60 °C |
Download
Logistics
| Zolltarifnummer | 85447000 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
