B2P-VH (LF)(SN) | JST
Pin header, 2 pole, pitch 3.96 mm, straight, white, B2P-VH (LF)(SN)
Unit Price (€ / pc.)
0.1785 € *
Available: 2,098 pcs.
Leadtime: 6 Weeks **
Total Price:
3.57 € *
Price list
Quantity
Price per unit*
20 pcs.
0.1785 €
100 pcs.
0.1607 €
500 pcs.
0.1452 €
*incl. VAT plus shipping costs
**Subject to prior sale
Headers for PCB assembly, top entry.
Rated current: 10 AUC. Rated voltage: 250 V AC/DC. Dielectric strength: 1500 VAC (60 s). Contact resistance (new state): max. 10 mohm. Insulation resistance: min. 1000 Mohm. Operating temperatures: - 25 to +85 °C. Certifications: UL, CSA.
Housing material: PA 66, UL 94 V-0. Color: plain colored (white). Connections: brass, copper-undercoated, tinned.
Technical attributes (type, number of poles, dimension A, dimension B): B2P-VH (LF)(SN), 2-pole, A 3.96 mm, B 7.86 mm
Technical specifications
| Anschluss | Lötstift | |
| Anschlussoberfläche | verzinnt | |
| Anzahl der Reihen | 1 | |
| Ausführung | Stiftleiste | |
| Bestückung | bestückt | |
| Farbe | weiß | |
| Kontaktart | Stift | |
| Kontaktoberfläche | verzinnt | |
| Nennspannung | 250 V | |
| Nennstrom | 10 A | |
| Orientierung | gerade | |
| Polzahl | 2-polig | |
| Rastermaß | 3.96 mm | |
| Verriegelung | Ja |
Download
Logistics
| Ursprungsland | MY |
| Zolltarifnummer | 85366990 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
