VHPR 500 H 10R K 300 | KRAH
Wirewound resistor, 10 Ω, 500 W, ±10 %, VHPR 500 H 10R K 300
Unit Price (€ / pc.)
104.2916 € *
Available: 0 pcs.
Leadtime: 8 Weeks **
Total Price:
104.29 € *
Price list
Quantity
Price per unit*
5 pcs.
104.2916 €
10 pcs.
102.1972 €
50 pcs.
96.9969 €
100 pcs.
94.9025 €
*incl. VAT plus shipping costs
**Subject to prior sale
Braking/power resistors, type KRAH VHPR.
In aluminum profile, high voltage/pulse strength
Braking/power resistors, 500 W, type VHPR 500.
Technical specifications
| ohmic resistance | 10 Ω | |
| Version | Braking/power wire-wound resistor | |
| Design | chassis | |
| Width | 60 mm | |
| Height | 31 mm | |
| Length | 337 mm | |
| Power | 500 W | |
| max. operating temperature | 200 °C | |
| min. operating temperature | -40 °C | |
| Assembly | chassis mounting | |
| Tolerance | ±10 % | |
| Temperature coefficient | -80/+1200 ppm/K |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85332900 |
| Original Packaging | Bulk with 5 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
