2170001 | LAPP
Coaxial cable, 50 Ω, RG 174 A/U, black
Unit Price (€ / mtr.)
0.9163 € *
Available: 206 mtr.
Leadtime: 1 Week **
Total Price:
0.92 € *
Price list
Quantity
Price per unit*
1 mtr.
0.9163 €
10 mtr.
0.8092 €
50 mtr.
0.7378 €
100 mtr.
0.6902 €
500 mtr.
0.6307 €
*incl. VAT plus shipping costs
**Subject to prior sale
Coaxial cable RG 174 A/U, 2170001, LAPP
The 2170001 is a coaxial cable for radio and computer systems as well as applications related to commercial radio-frequency (high frequency) technology and electronics. It allows distortion-free and low-attenuation transmission of signals with a high bandwidth over shorter distances and were designed for operating frequencys up to 1 GHz. The cable is intended for limited movements and for fixed installation in dry and damp interiors and outdoors. It meets the requirements concerning high ambient temperatures and chemical stress.
Features
- Flame-retardant
- Mechanical and plant engineering
- Suitable for outdoor use
- Cold-resistant
- UV-resistant
Technical specifications
| Outer diameter | 2.8 mm | |
| Dielectric material | PE | |
| Dielectric diameter | 1.52 mm | |
| Colour | schwarz | |
| Impedance | 50 Ω | |
| Capicity/m | 101 pF/m | |
| Material | PVC | |
| max. operating temperature | 80 °C | |
| min. operating temperature | -40 °C | |
| Shielding | geschirmt |
Download
Logistics
| Country of origin | IT |
| Customs tariff number | 85442000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
