4533113 | LAPP
Rubber connection cable H07RN-F, erweiterte Version 12 G 1.5 mm², unshielded, black, 4533113
Order No.: 33P3215
EAN: 4044776710325
MPN:
4533113
H07RN-F, ENHANCED VERSION 12G1,5
Series: H07RN-F, erweiterte Version
Unit Price (€ / mtr.)
18.2427 € *
Available: 0 mtr.
Leadtime: On Request **
Power and control cable, 4533113, LAPP
The 4533113 designed for connecting equipment for heavy stress and connecting industrial and agricultural machines where cables underlie medium mechanical stress. and connecting industrial and agricultural machines where cables underlie medium mechanical stress. (e.g. machine tools, hot plates, lamps, electrical tools). In compliance with recommended application acc to. DIN EN 50565-2, H07RN-F, enhanced version is suitable for use in dry, damp or wet rooms as well as outdoors. Fixed installation such as on plaster in provisory buildings and barracks are allowed. Continuous operational movements, restricted guidance, usage of these cables in moving cable carriers or on motor drum guidance or under a strain of more than 15 N/mm².
Technical specifications
| Aderisolationsmaterial | Gummi | |
| Adernfarbe | schwarz | |
| Anzahl der Adern | 12 | |
| Ausführung | Anschlussleitung | |
| Außendurchmesser | 22.4 mm | |
| Farbe | schwarz | |
| Halogenfrei | Yes | |
| Leiterklasse | Kl.5 = feindrähtig | |
| Leitermaterial | Kupfer, blank | |
| Leiterquerschnitt | 1,5 mm² | |
| Material | Gummi | |
| Nennspannung | 750 V | |
| Nennspannung U0 | 450 V | |
| Prüfspannung | 2.5 kV | |
| Schirmung | ungeschirmt | |
| Schleppkettentauglich | No | |
| Schutzleiter vorhanden | Yes | |
| Temperaturbereich (bewegt) | -40 °C bis 90 °C | |
| Temperaturbereich (unbewegt) | -50 °C bis 90 °C |
Download
Logistics
| Ursprungsland | IT |
| Zolltarifnummer | 85444995 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
