0031327/100 | LAPP
PUR data cable, 4-wire, 0.34 mm², gray, 0031327/100
Order No.: 32P4153
EAN: 4044774737935
MPN:
0031327/100
UNITRONIC Li2YCY (TP) 4x2x0,34
Series: UNITRONIC Li2YCY (TP)
Unit Price (€ / mtr.)
5.4026 € *
Available: 0 mtr.
Leadtime: On Request **
PVC data cable, 0031327/100, LAPP KABEL
Screened data transmission cable with PE core insulation. Low-frequency, low-capacitance screened PVC data cable.
Features
- Flame-retardant
- Interference signals
- Overall braid minimises electrical interference
- Can be used in dry or damp rooms
Technical specifications
| Aderisolationsmaterial | PVC | |
| Anzahl der Adern | 4 | |
| Ausführung | Datenkabel | |
| Außendurchmesser | 8.4 mm | |
| Farbe | grau | |
| Halogenfrei | No | |
| Leitermaterial | Kupfer, blank | |
| Leiterquerschnitt | 0,34 mm² | |
| Material | PUR | |
| Schirmung | ungeschirmt | |
| Temperaturbereich (bewegt) | -5 °C bis 70 °C | |
| Temperaturbereich (unbewegt) | -40 °C bis 80 °C |
Download
Logistics
| Ursprungsland | MY |
| Zolltarifnummer | 85444993 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
