61742490 | LAPP

Heatshrink tubing, 2:1, (1.6/0.8 mm), PE, black, 61742490

Order No.: 33P6600
EAN: 4056156189348
MPN:
61742490
PROTECT-HF BOX1,6/0,8 BK
Series: PROTECT-HF
61742490 LAPP Heat Shrink Tubing
Image may differ
Unit Price (€ / pc.)
30.0118 € *
Available: 2 pcs.
Leadtime: 1 Week **
Total Price:
30.01 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
30.0118 €

Shrink tubing, 61742490, LAPP

The shrink tube is halogen-free and therefore particularly interesting for use in public buildings, airports, hospitals, etc. The shink tube PROTECT-HF RW has also a Railway approval.

Features

  • Halogen-free
  • Good chemical resistance
  • Flame retardant
  • Silicone-free
  • UV-resistant

Applications

  • Insulation, protection and cable bundling
  • Green-yellow shrink tube: For identifying and marking earthing connectors and cables
  • Assembly lines, production lines, in all kinds of machines
  • For railway applications and marking systems
Technical specifications
Farbe schwarz
Innendurchmesser nach Schrumpfung 0.8 mm
Innendurchmesser vor Schrumpfung 1.6 mm
Länge 15 m
Material PE
max. Temperatur 105 °C
min. Temperatur -30 °C
Schrumpfrate 2:1
Schrumpftemperatur 90 °C
Wanddicke 0.43 mm
Zollgröße 1/16
Logistics
Ursprungsland PL
Zolltarifnummer 39173200
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei Yes
