0071105 | LAPP
Silicone-switching wire, halogen free, ÖLFLEX HEAT 180 SiD, 1.5 mm², white, outer Ø 2.6 mm, 0071105
Order No.: 33P1064
EAN: 4044774690414
MPN:
0071105
ÖLFLEX HEAT 180 SiD 1X1,5 WH
Series: ÖLFLEX HEAT 180 SiD
Unit Price (€ / mtr.)
1.1662 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Total Price:
1.17 € *
Price list
Quantity
Price per unit*
1 mtr.
1.1662 €
10 mtr.
1.0234 €
50 mtr.
0.9401 €
100 mtr.
0.8568 €
500 mtr.
0.8092 €
*incl. VAT plus shipping costs
**Subject to prior sale
Technical specifications
| Core insulation material | silicone | |
| Outer diameter | 2.6 mm | |
| Colour | white | |
| Halogen free | Yes | |
| Conductor category | CL.1 = stranded | |
| Cable material | copper, tin-plated | |
| Cable cross-section | 1.5 mm² | |
| Rated voltage | 500 V | |
| Rated voltage U0 | 300 V | |
| Test voltage | 2 kV | |
| Temperature range (unmoved) | -50 to 180 °C | |
| Bending radius moved | 7.8 mm | |
| Bending radius unmoved | 15.6 mm |
Download
Logistics
| Country of origin | IT |
| Customs tariff number | 85444991 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
