4726027 | LAPP
Polymer-Stranded wire, high flexible, halogen free, H07Z-K, 25 mm², blue, outer Ø 10.6 mm, 4726027
Unit Price (€ / mtr.)
9.1987 € *
Available: 0 mtr.
Leadtime: On Request **
Total Price:
9.20 € *
Price list
Quantity
Price per unit*
100 mtr.
9.1987 €
500 mtr.
8.4609 €
*incl. VAT plus shipping costs
**Subject to prior sale
Stranded wire, high flexible, 4726027, LAPP KABEL
Halogen-free core cable, harmonized. For the use in control cabinet, rated voltage 450/750 V.
Features
- Low corrosiveness of the gases in case of fire
- Low smoke development/smoke gas density in case of fire
- Flame retardant
Applications
- For wiring lights, devices, switchgear and distribution boards
- For installation in pipes, on, in and under plaster as well as in closed installation ducts
- In buildings with a high concentration of persons or material values
- For use in dry rooms
Technical specifications
| Aderisolationsmaterial | Polymer | |
| Außendurchmesser | 10.6 mm | |
| Farbe | blau | |
| Halogenfrei | Yes | |
| Leiterklasse | Kl.5 = feindrähtig | |
| Leitermaterial | Kupfer, blank | |
| Leiterquerschnitt | 25 mm² | |
| Nennspannung | 750 V | |
| Nennspannung U0 | 450 V | |
| Norm | HAR | |
| Prüfspannung | 2.5 kV | |
| Temperaturbereich (bewegt) | 5 °C bis 90 °C | |
| Temperaturbereich (unbewegt) | -40 °C bis 90 °C |
Download
Logistics
| Ursprungsland | IT |
| Zolltarifnummer | 85444995 |
| Originalverpackung | Ring mit 100 Meter |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
