PVC motor connection cable ÖLFLEX SERVO 2XSLCY-JB 4 G 240 mm², shielded, black, 1133614
Order No.: 33P1950
EAN: 4056155300089
MPN:
1133614
ÖLFLEX SERVO 2XSLCY-JB 4G240
Series: ÖLFLEX SERVO 2XSLCY-JB
Unit Price (€ / mtr.)
322.2282 € *
Available: 0 mtr.
Leadtime: 6 Weeks **
Total Price:
32,222.82 € *
*incl. VAT plus shipping costs
**Subject to prior sale
100 mtr.
322.2282 €
Motor connection cable, 1133614, LAPP
Flexible cable, having special EMC-performance due to double shield, with low capacitance design and PVC sheath. The cable is ideal suitable for three-phase motors of small, medium and large sizes operated by frequency converters.
Features
- Low-capacitance design
- Flame-retardant
- UV and weather-resistant
- Flexible at temperatures down to -15 °C
Applications
- Connecting cable between frequency converter and motor
- For use in dry, damp and wet rooms
- Paper industry
- Chemical industry
- Heavy industry
Technical specifications
| Aderisolationsmaterial | XLPE | |
| Adernfarbe | VDE 0293-308 | |
| Anzahl der Adern | 4 | |
| Ausführung | Motoranschlussleitung | |
| Außendurchmesser | 65.6 mm | |
| Farbe | schwarz | |
| Halogenfrei | No | |
| Leiterklasse | Kl.5 = feindrähtig | |
| Leitermaterial | Kupfer, blank | |
| Leiterquerschnitt | 240 mm² | |
| Material | PVC | |
| Nennspannung | 1 kV | |
| Nennspannung U0 | 600 V | |
| Nennspannung UL/CSA | 1 kV | |
| Prüfspannung | 4 kV | |
| Schirmung | geschirmt | |
| Schutzleiter vorhanden | Yes | |
| Temperaturbereich (bewegt) | -15 °C bis 90 °C | |
| Temperaturbereich (unbewegt) | -40 °C bis 90 °C |
Download
Logistics
| Ursprungsland | IT |
| Zolltarifnummer | 85444999 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
