15500213/50 | LAPP
PVC earth cable NYY-J 4 G 6.0 mm², unshielded, 15500213/50
Unit Price (€ / mtr.)
5.9857 € *
Available: 0 mtr.
Leadtime: On Request **
Total Price:
5.99 € *
Price list
Quantity
Price per unit*
1 mtr.
5.9857 €
10 mtr.
5.4383 €
50 mtr.
4.9028 €
100 mtr.
4.4863 €
500 mtr.
4.0817 €
*incl. VAT plus shipping costs
**Subject to prior sale
Technical specifications
| Core insulation material | PVC | |
| Core colour sequence | VDE 0293-308 | |
| Number of cores | 4 | |
| Version | earth cable | |
| Outer diameter | 17 mm | |
| Halogen free | No | |
| Cable material | copper, bright | |
| Cable cross-section | 6.0 mm² | |
| Material | PVC | |
| Rated voltage | 1 kV | |
| Rated voltage U0 | 600 V | |
| Test voltage | 4 kV | |
| Shielding | unshielded | |
| Protective conductor available | Yes | |
| Temperature range (active) | -5 °C to 50 °C | |
| Temperature range (unmoved) | -40 °C to 70 °C |
Download
Logistics
| Country of origin | PL |
| Customs tariff number | 85444999 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
