61815160 | LAPP

Corrugated hose, inside Ø 36 mm, outside Ø 42.5 mm, BR 80 mm, PA, gray, 61815160

Order No.: 32P970
EAN: 4044773373219
MPN:
61815160
SILVYNTCNW RILLPA12 42/36x42,
Series: SILVYN RILL
LAPP
61815160 LAPP Protective Tubes
Image may differ
Print
Key Specification:
Inner diameter 36 mm
Outer diameter 42.5 mm
Nominal width 42 mm
Bending radius 80 mm
Material PA
Show 8 variants
Download Datasheet Technical specifications
Unit Price (€ / mtr.)
27.8222 € *
Available: 0 mtr.
Leadtime: On Request **
Add to Cart
Total Price:
27.82 € *
*incl. VAT plus shipping costs
**Subject to prior sale
25 mtr.
27.8222 €
Description
Technical specifications
Download
Logistics
Compliance
Variations
Technical specifications
Outer diameter 42.5 mm
Bending radius 80 mm
Colour gray
Flame-retardant Yes
Inner diameter 36 mm
Material PA
max. operating temperature 100 °C
min. operating temperature -50 °C
Nominal width 42 mm
Degree of protection (IP) IP67
Show similar products 0
Logistics
Country of origin DE
Customs tariff number 39173200
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
