61802069 | LAPP
Insulated wire end ferrule, 16 mm², 23 mm/12 mm long, DIN 46228/4, blue, 61802069
Order No.: 33P4221
EAN: 4044773799224
MPN:
61802069
ADERENDHÜLSEN XL 16,0 BU 12
Unit Price (€ / pc.)
0.1845 € *
Available: 100 pcs.
Leadtime: 1 Week **
Total Price:
0.18 € *
Price list
Quantity
Price per unit*
1 pcs.
0.1845 €
10 pcs.
0.1595 €
50 pcs.
0.1404 €
100 pcs.
0.1226 €
500 pcs.
0.1142 €
*incl. VAT plus shipping costs
**Subject to prior sale
Conductor end sleeve, 61802069, LAPP
The 61802069 is an insulated conductor end sleeves for short circuit cables up to 3 kV, for cables with thick insulation and greater wall thickness for higher loads.
Features
- Halogen-free
Applications
- Special conductor end sleeve model with large plastic collar for thick insulation cables
- Suitable for unprotected connections on control and distribution panels, rail vehicles, solar systems, ignition cables
Technical specifications
| Colour | blue | |
| Material Insulation | polypropylene | |
| Isolated | Yes | |
| Contact material | electrolytic copper | |
| Length | 23 mm | |
| Cable cross-section | 16 mm² | |
| max. operating temperature | 105 °C | |
| Standard number | DIN 46228/4 | |
| Pin lenght | 12 mm |
Download
Logistics
| Customs tariff number | 85369010 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
