IXDI630CI | Littelfuse
Low-side ultrafast MOSFET driver, TO-220, Littelfuse IXDI630CI
Unit Price (€ / pc.)
7.6160 € *
Available: 0 pcs.
Available in 4 Days: 200 pcs.
Leadtime: 16 Weeks **
Gate driver, IXDI630CI, Littelfuse
The IXDI630CI is a high-speed gate driver that is especially well suited for driving the latest IXYS power MOSFETs and IGBTs. The output can source and sink 30 A of peak current while producing voltage rise and fall times of less than 20 ns. Internal circuitry eliminates cross conduction and current "shoot-through" and the driver is virtually immune to latch up.
Features
- Fast Rise and Fall Times
- Low Propagation Delay Time
- Low Output Impedance
- Under-Voltage Lockout Protection
Applications
- Switch-Mode Power Supplies
- DC-DC Converters
- Motor Controllers
- Pulse Transformer Driver
- Class-D Switching Amplifiers
Technical specifications
| Anzahl der Kanäle | 1 | |
| Ausführung | Niedrige Seite | |
| Gehäuse | TO-220 | |
| Montage | THT |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85411000 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
