IXGP12N120A3 | Littelfuse
IGBT, 1200 V, 12 A, TO-247, Littelfuse IXGP12N120A3
Order No.: 74P0798
EAN: 4099891776633
MPN:
IXGP12N120A3
Unit Price (€ / pc.)
2.8084 € *
Available: 0 pcs.
Leadtime: 52 Weeks **
IGBT, IXGP12N120A3, LITTELFUSE
Ultra-low Vsat PT IGBT for up to 3 kHz switching with an international standard package, optimized for low conduction losses, and with advantages such as high power density, and low gate drive requirements.
Applications
- Power inverters
- UPS
- Motor drives
- SMPS
- PFC circuits
- Battery chargers
- Welding machines
- Lamp ballasts
- Inrush current protection circuits
Technical specifications
| Ausführung | Einfach | |
| Gehäuse | TO-247 | |
| max. Spannung | 1200 V | |
| max. Strom | 12 A | |
| max. Temperatur | 150 °C | |
| min. Temperatur | -55 °C | |
| Montage | THT | |
| Sättigungsspannung | 3 V | |
| Verlustleistung VA (AC) | 100 W |
Download
Logistics
| Ursprungsland | KR |
| Zolltarifnummer | 85411000 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
