1210L150THWR | Littelfuse
PTC fuse, self-resetting, SMD 1210, 6 V (DC), 100 A, 3 A (trip), 1.5 A (hold), 1210L150THWR
Unit Price (€ / pc.)
0.3808 € *
Available: 0 pcs.
Leadtime: 13 Weeks **
PTC fuse, 1210L150THWR, LITTELFUSE
The surface-mount resettable PPTC provides overcurrent protection for applications where space is at a premium and resettable protection is desired.
Features
- RoHS compliant, lead-free and halogen-free
- Fast response to fault currents
- Compact design saves board space
- Low resistance
- Low profile
- Compatible with high temperature solders
Applications
- USB peripherals
- Disk drives
- CD-ROMs
- PC motherboards - plug and play protection
- Mobile phones - battery and port protection
- PDAs/digital cameras
- Game console port protection
Technical specifications
| Activation time | 300 ms | |
| Trigger current | 3 A | |
| Design | SMD 1210 | |
| max. holding current | 1.5 A | |
| Rated voltage (DC) | 6 V | |
| Rated current | 100 A |
Download
Logistics
| Country of origin | PH |
| Customs tariff number | 85332900 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
