CLA60MT1200NTZ-TRL | Littelfuse
Triac, 1200 V (RRM), TO-268AA, Littelfuse CLA60MT1200NTZ-TRL
Order No.: 74P0049
EAN: 4099891769147
MPN:
CLA60MT1200NTZ-TRL
Unit Price (€ / pc.)
8.0682 € *
Available: 0 pcs.
Leadtime: 23 Weeks **
Triac, CLA60MT1200NTZ-TRL, Littelfuse
Triac, a planar passivated chip with three quadrants operation and long-term stability of blocking currents and voltages.
Features
- Industry standard outline
- RoHS compliant
- Epoxy meets UL 94V-0
- High creepage distance between terminals
Applications
- Line rectifying 50/60 Hz
- Softstart AC motor control
- DC motor control
- Power converter
- AC power control
- Lighting and temperature control
Technical specifications
| Anzahl der Pins | 3 | |
| Ausführung | Triac | |
| Gate-Trigger-Spannung | 1.7 V | |
| Gate-Trigger-Strom | 60 mA | |
| Gehäuse | TO-268AA | |
| Haltestrom | 60 mA | |
| max. Temperatur | 125 °C | |
| min. Temperatur | -40 °C | |
| Montage | SMD | |
| Spannung V RRM (Spitzensperrspannung) | 1200 V | |
| Spannungsanstiegsraten dV/dt | 500 V/s |
Download
Logistics
| Ursprungsland | KR |
| Zolltarifnummer | 85413000 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
