V10E510P | Littelfuse
Varistor, radial, VV 820 V, 3500 A, 670 V (DC), 510 V (AC), 92 J, V10E510P
Unit Price (€ / pc.)
0.2713 € *
Available: 0 pcs.
Leadtime: 12 Weeks **
Varistor, V10E510P, Littelfuse
The V10E510P is an Epoxy Coated, Radial Leaded Varistor designed for applications requiring high peak surge current ratings and high energy absorption capability.
Features
- Lead-free
- Halogen-Free
- RoHS compliant
Applications
- Transient Voltage Surge Suppressors
- Uninterruptable Power Supplies
- AC Power Taps
- AC Power Meters
Technical specifications
| Design | radial | |
| Energy absorption | 92 J | |
| max. Surge current, transient (8/20 µs) | 3500 A | |
| max. operating temperature | 85 °C | |
| min. operating temperature | -55 °C | |
| Rated voltage (AC) | 510 V | |
| Rated voltage (DC) | 670 V | |
| Grid | 8.5 mm | |
| Varistor Voltage Type | 820 V |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85334090 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
