11318 | Lumberg Automation

Sensor actuator cable, M8-cable socket, angled to open end, 3 pole, 2 m, PVC, orange, 4 A, 11318

Order No.: 72F1692
EAN: 4099891165352
MPN:
11318
RKMW/LED A 3-06/2M
Series: RKMW
Lumberg Automation
11318 Lumberg Automation Sensor-Actuator Cables
Image may differ
Unit Price (€ / pc.)
15.8865 € *
Available: 0 pcs.
Leadtime: 10 Weeks **
Total Price:
15.89 € *
*incl. VAT plus shipping costs
**Subject to prior sale
10 pcs.
15.8865 €

Actuator/sensor single-ended cordset, RKMW/LED A 3-06/2M, Lumberg Automation

M8 Snap-In Actuator/sensor single-ended cordset: Female, angled, 3-pin, A-coded, translucent body, 10-30 V DC, 4 A, with 2xLEDs (PNP); PVC orange cable, 3-wires, 0.34 mm².

Technical specifications
Connection (1) M8-cable socket, angled
Connection (2) open end
Colour orange
Cable length 2 m
LED display Yes
Material PVC
max. Voltage 30 V
Rated current 4 A
Pin number 3 pole
Degree of protection (IP) IP65
Logistics
Country of origin CZ
Customs tariff number 85444290
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
