1931 | Lumberg Automation
Plug, M12, 5 pole, solder connection, screw locking, straight, 1931
Unit Price (€ / pc.)
9.7223 € *
Available: 0 pcs.
Leadtime: 15 Weeks **
Sensor-actuator connector, 1931, Lumberg Automation
M12 Standard Sensor/actuator receptacle connector: male, rear mount, M12 - mating side, stranded wires - connecting side, 5-pin, unshielded, metallic grey housing, 50 V AC/60 V DC, 4 A.
Features
- Contact material: CuZn
- Pollution degree: 3
- Overvoltage category: III
Technical specifications
| Version | Stecker | |
| Thread size | M12 | |
| Coding | A | |
| Contact connection | Lötanschluss | |
| contact surface | vergoldet | |
| Assembly | Rückseitige Montage | |
| Orientation | gerade | |
| Pin number | 5-polig | |
| Degree of protection (IP) | IP67/IP69K | |
| Type of locking | Schraubverriegelung |
Download
Logistics
| Country of origin | CZ |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Octamethylcyclotetrasiloxan, Decamethylcyclopentasiloxan, Dodecamethylcyclohexasiloxan, Blei |
