KRE 09 | Lumberg
PCB terminal, 9 pole, pitch 5 mm, AWG 22-14, 15 A, screw connection, light gray, KRE 09
Unit Price (€ / pc.)
3.1416 € *
Available: 11 pcs.
Leadtime: On Request **
Total Price:
3.14 € *
Price list
Quantity
Price per unit*
1 pcs.
3.1416 €
10 pcs.
2.7608 €
100 pcs.
2.4157 €
250 pcs.
2.3324 €
1000 pcs.
2.1777 €
*incl. VAT plus shipping costs
**Subject to prior sale
Screw terminal block,
For vertical mounting on PCBs, with single-row solder terminals and misplacement protection. Practical splitting for user-specific in-line installation; Contact carrier: PA 6.6, V2 to UL 94, light-gray. Terminal body: steel, galvanized and chromalized. Grid: 5.0 mm. Screw: M 2.6. Conductor cross-sections: max. 4.0 mm². Rated current: 15 A. Rated voltage to DIN VDE 0110/IEC 60664: 250 VAC. Test Voltage: 3.0 kV/60 s. Leakage current resistance: CTI 600. Air gap/creepage distance: to DIN VDE 0110/IEC 60664: 3.6/3.6 mm. Operating temperatures: –25 to +100 °C. Certifications: UL, CSA.
Technical attributes (type, number of poles, strip length): KRE 09, 9–pole, 45 mm
Technical specifications
| Anschluss | Schraubanschluss | |
| AWG-Leiterquerschnitt | AWG 22-14 | |
| Breite | 10 mm | |
| Farbe | hellgrau | |
| Höhe | 19.3 mm | |
| Kontaktabstand | RM 5/5,08 | |
| Leiterquerschnitt | 4,0 mm² | |
| Nennspannung | 250 V | |
| Nennstrom | 15 A | |
| Polzahl | 9-polig | |
| Rastermaß | 5 mm | |
| Tiefe | 15.5 mm |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85369010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
