2440 09 T09CB A | Lutronic
Jack, 9 pole, solder cup, quick locking, straight, 2440 09 T09CB A
Unit Price (€ / pc.)
9.4248 € *
Available: 45 pcs.
Leadtime: On Request **
Total Price:
9.42 € *
Price list
Quantity
Price per unit*
1 pcs.
9.4248 €
10 pcs.
8.6751 €
50 pcs.
7.8897 €
100 pcs.
7.1043 €
*incl. VAT plus shipping costs
**Subject to prior sale
Quicklock circular connector, 0261 09, Lumberg
Quicklock socket, IP67, size 16, straight version, with plastic housing and solder terminals
Technical Data
- Contact connection: Solder cup
- Rated voltage: 400 V
- Number of positions: 9
- Cable cross-section: 0.25-0.34 mm²
- Shell material: PBT
Technical specifications
| Version | jack | |
| Additional parts | equipped | |
| Shell Material | PBT | |
| Cable diameter | 3 to 9 mm | |
| Contact connection | solder cup | |
| contact surface | gold-plated | |
| Cable cross-section | 0.25-0.34 mm² | |
| Assembly | cable assembly | |
| Orientation | straight | |
| Pin number | 9 pole | |
| Type of locking | quick locking |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
