2640 02 T12CB A | Lutronic
Jack, 2 pole, solder cup, quick locking, straight, 2640 02 T12CB A
Unit Price (€ / pc.)
12.3046 € *
Available: 1 pcs.
Leadtime: 20 Weeks **
Total Price:
12.30 € *
Price list
Quantity
Price per unit*
1 pcs.
12.3046 €
10 pcs.
11.3169 €
50 pcs.
10.3054 €
100 pcs.
9.2820 €
*incl. VAT plus shipping costs
**Subject to prior sale
Quicklock circular connector, 0262 02, Lumberg
Quicklock socket, IP67, size 20, straight version, with plastic housing and solder terminals
Technical Data
- Contact connection: Solder cup
- Rated voltage: 500 V
- Number of positions: 2
- Cable cross-section: 2.5-4.0 mm²
- Shell material: PBT
Technical specifications
| Version | Kupplung | |
| Cable cross-section | 2,5-4,0 mm² | |
| Pin number | 2-polig | |
| Orientation | gerade | |
| Contact connection | Lötkelch | |
| Type of locking | Schnellverriegelung | |
| Cable diameter | 7 bis 13 mm | |
| Assembly | Kabelmontage | |
| Additional parts | bestückt | |
| contact surface | vergoldet | |
| Shell Material | PBT |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
