1205 12 315 5M | Lutronic
Sensor actuator cable, M12-cable socket, angled to open end, 12 pole, 5 m, PUR, black, 1.5 A, 1205 12 315 5M
Order No.: 48F192
EAN: 4099891106164
MPN:
1205 12 315 5M
Unit Price (€ / pc.)
49.0399 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
49.04 € *
Price list
Quantity
Price per unit*
1 pcs.
49.0399 €
10 pcs.
45.6246 €
25 pcs.
41.9594 €
50 pcs.
38.6036 €
*incl. VAT plus shipping costs
**Subject to prior sale
Sensor/actuator cable with molded connector, one side with angled M12 female connector, A-coded, 12 poles, other side with open ends, 12 x 0.25 mm² (AWG 24), cable material: PUR, black, 5 m long, according to UL style 20549. Rated voltage: 30 V (at pollution degree 3), rated current: 1.5 A (at 40 °C), rated impulse voltage: 0.5 kV, protection class: IP67, temperature range: -25 °C to 80 °C.
Technical specifications
| Connection (1) | M12-cable socket, angled | |
| Connection (2) | open end | |
| Colour | black | |
| Cable length | 5 m | |
| LED display | No | |
| Material | PUR | |
| max. Voltage | 30 V | |
| Rated current | 1.5 A | |
| Pin number | 12 pole | |
| Degree of protection (IP) | IP67 |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85444290 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
