1010.3001 | Marquardt
Snap acting switche, On-On, solder connection, roller hinge lever, 0.25-0.6 N, 2 (0.5) A/250 VAC, IP50, 1010.3001
Snap-action switches, open, series 1010, type Marquardt 1010.
To DIN 41635 C, open design; Switching action: CO. Breaking capacity: 2,0 (0,5) A/250 VAC 20E4. Contact resistance (new condition): max. 100 mohm (1.0 A/12 VDC). Insulation resistance (new condition): min. 100 Mohm (500 VDC). Leakage current resistance: PTI 250. Insulation gap: to EN 61058 for reinforced or double insulation. Contact pitch: less than 3.0 mm. Contact material: Ag. Terminals: silver-plated. Socket material: PA. Inflammability: UL 94 V-2. Operating temperatures: –20 to +85 °C.
With 6.5 mm solder terminals and actuating cam.
Differential travel: max. 0.9 mm. Pretravel: max. 3.3 mm. Overtravel: 0.5 mm.
Technical attributes (type, switch actuating force): 1010.3001, 0.25 to 0.60 N/m
| Anschluss | Lötanschluss | |
| Bauform | abgewinkelt | |
| Betätiger | Rollenscharnierhebel | |
| Betätigungskraft | 0,25-0,6 N | |
| Gehäusematerial | PA | |
| Schaltfunktion | Ein-Ein | |
| Schaltleistung | 2 (0,5) A/250 VAC | |
| Schaltpunkt | 0,9 mm ±0,6 mm | |
| Schutzart (Betätigungsseite) | IP50 |
| Ursprungsland | DE |
| Zolltarifnummer | 85365080 |
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
