6425.6111 | Marquardt
Short-stroke pushbutton, 1 Form A (N/O), 100 mA/28 V, illuminated, red, actuator (white, L 4.3 mm), 0.7 N, THT, 6425.6111
Keyswitches, type Marquardt 6425.
Anthracite colored keycap, raised toggle with small rounded touch area. The key module is therefore particularly suitable for recessed front-panel mounting with or without LED bore. With 1 x NO contact; Pitch: 16 mm, or 15 mm. Breaking capacity: maximum 28 V/100 mA. Contact resistance ( new condition): max. 250 mohm. Bounce: less than 5.0 ms. Actuating force: approx. 0.7 N. Total travel: 1.6 mm. Ambient temperatures: –20 to +70 °C. Contacts: gold. Connections: tinned. Housing: PBTP. Frame cutout: 13.55 x 13.55 mm. Panel thickness: 1.2 mm. This key module is supplied without keycap.
Keyswitches with raised LED, type 6425.
Note: current to the integrated LED must be limited to max. 20 mA.
Type: 6425.6111, keyswitch with red LED
| Anschluss | THT | |
| beleuchtet | Yes | |
| Betätigungskraft | 0,7 N | |
| Breite | 14.4 mm | |
| Farbe Betätiger | weiß | |
| Farbe der Beleuchtung | rot | |
| Höhe | 10.7 mm | |
| Kontaktmaterial | vergoldet | |
| Länge | 14.8 mm | |
| Schaltfunktion | 1 Schließer | |
| Schaltleistung | 100 mA/28 V | |
| Betätigerlänge | 4.3 mm |
| Ursprungsland | DE |
| Zolltarifnummer | 85365011 |
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
