HDR-60-12 | MEAN WELL
Power supply, 10.8 to 13.8 VDC, 4.5 A, 54 W, HDR-60-12
Unit Price (€ / pc.)
33.0701 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
33.07 € *
Price list
Quantity
Price per unit*
1 pcs.
33.0701 €
5 pcs.
31.0828 €
50 pcs.
27.5128 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power supply, HDR-60-12, MEAN WELL
HDR-60-12 is an economical, ultra-slim 60W DIN rail power supply. The housing is 52.5 mm wide, which allows space savings in cabinets. This unit is suitable for the entire input range from 85 VAC to 264 VAC. With a working efficiency of up to 91%, it can operate at an ambient temperature between -30 °C and 70 °C under air convection.
Features
- Power consumption without load <0.3 W
- Insulation class II
- Limited energy source
- DC output voltage adjustable
- Protection functions: Short circuit, overload, overvoltage
- Cooling by free air convection
- LED indicator for power on
Applications
- Budgetary control system
- Building automation
- Industrial control system
- Factory automation
- Electro-mechanical device
Technical specifications
| Number of outputs | 1 | |
| Output voltage DC | 10.8 to 13.8 VDC | |
| Output current | 4.5 A | |
| Width | 52.5 mm | |
| Input voltage AC | 85-264 VAC, 120-370 VDC | |
| Height | 90 mm | |
| Power | 54 W | |
| Depth | 54.5 mm | |
| efficiency | 88 % |
Download
Logistics
| Country of origin | CN |
| Customs tariff number | 85043180 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
