MDR-40-24 | MEAN WELL
Power supply, 24 to 30 VDC, 1.7 A, 40 W, MDR-40-24
Unit Price (€ / pc.)
30.6901 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
30.69 € *
Price list
Quantity
Price per unit*
1 pcs.
30.6901 €
5 pcs.
28.8456 €
50 pcs.
25.5255 €
*incl. VAT plus shipping costs
**Subject to prior sale
Power supply, MDR-40-24, MEAN WELL
AC-DC Industrial DIN rail power supply, output 24 VDC at 1.7 A, plastic housing.
Features
- Universal AC input/full range
- Protection functions: Short circuit, overload, overvoltage
- Cooling by free air convection
- LED indicator for power on
- DC OK relay contact
- Power consumption without load < 0.75 W
- 100 % full load burn-in test
Technical specifications
| Anzahl der Ausgänge | 1 | |
| Ausgangsspannungsbereich | 24 bis 30 VDC | |
| Ausgangsstrom | 1.7 A | |
| Breite | 40 mm | |
| Eingangsspannungsbereich | 85-264 VAC, 120-370 VDC | |
| Höhe | 90 mm | |
| Leistung | 40 W | |
| Tiefe | 100 mm | |
| Wirkungsgrad | 88 % |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85043180 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
