1668 | Mennekes
CEE surface-mounted socket, 3 pole, 16 A/230 V, blue/gray, 6 h, IP44, 1668
Order No.: 12N189
EAN: 4015394210269
MPN:
1668
Unit Price (€ / pc.)
94.9025 € *
Available: 0 pcs.
Leadtime: 4 Weeks **
Total Price:
94.90 € *
Price list
Quantity
Price per unit*
1 pcs.
94.9025 €
2 pcs.
92.0465 €
5 pcs.
87.4412 €
10 pcs.
81.3246 €
*incl. VAT plus shipping costs
**Subject to prior sale
With TwinCONTACT, type 16.
Splashproof to IP 44, straight insertion, with mounting flange and hinged lid. Version: to DIN VDE 0623, EN 60309-2. Color: electrical-gray and/or color code. Housing and insert: made of high strength plastic (AMAPLAST). Contacts (number of poles/contact type): 3-pole/2 P + E, 5-pole/3 P + N + E. Termination: screw terminals. Table index: type, number of poles, rated current, operating voltage (50/60 Hz), color code.
Screwless spring clamp technology. Suitable for race wiring.
Type: 1668, 3 - pole, 16 A, 230 V, blue
Technical specifications
| Connection | spring-clamp connection | |
| Version | surface-mounted socket | |
| Colour | blue/gray | |
| Frequency range | 50 to 60 Hz | |
| Cable cross-section | 1.5-4.0 mm² | |
| Nominal power | 16 A/230 V | |
| Pin number | 3 pole | |
| Degree of protection (IP) | IP44 |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
