332 | Mennekes
CEE wall plug, 3 pole, 16 A/230 V, blue, 6 h, IP44, 332
Order No.: 12N660
EAN: 4015394002376
MPN:
332
Unit Price (€ / pc.)
106.9810 € *
Available: 0 pcs.
Leadtime: 3 Weeks **
Total Price:
106.98 € *
Price list
Quantity
Price per unit*
1 pcs.
106.9810 €
2 pcs.
103.7680 €
5 pcs.
98.5796 €
10 pcs.
91.6776 €
*incl. VAT plus shipping costs
**Subject to prior sale
Wall mount CEE inlets, type Mennekes 332/342/354.
Splashproof to IP 44, with mounting flange; Cable entries: 16 A version with one M 20 entry on top and one dummy plug on the bottom (for cutting out), 32 A version with one M 32 on top and two M 25 dummy plugs on the bottom (for cutting out). Version: to DIN VDE 0623, EN 60309-2. Color: electrical-gray and/or color code. Housing and insert: made of high strength plastic (AMAPLAST). Contacts (number of poles/contact type): 3-pole/2 P + E, 5-pole/3 P + N + E.
Technical attributes (type, rated current, number of poles, operating voltage (50/60 Hz), color code): 332, 16 A, 3–pole, 230 V, blue
Technical specifications
| Connection | screw connection | |
| Version | wall plug | |
| Colour | blue | |
| Frequency range | 50 to 60 Hz | |
| Cable cross-section | 1.0-2.5 mm² | |
| Nominal power | 16 A/230 V | |
| Pin number | 3 pole | |
| Degree of protection (IP) | IP44 |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | No |
| Substance description | Lead |
