100-26TBK | METCAL

Name: ETFE-wire wrap switching wire, 0.13 mm², AWG 26, black, outer Ø 0.71 mm, 100-26TBK
Brand: METCAL
SKU: 91F5012
Availability: OutOfStock

ETFE-wire wrap switching wire, 0.13 mm², AWG 26, black, outer Ø 0.71 mm, 100-26TBK

Order No.: 91F5012

EAN: 4099891168698

MPN:

100-26TBK

Series: TEFZEL WIRE

Image may differ

Key Specification:

Cable cross-section 0.13 mm²

AWG cross-section AWG 26

Colour black

Core insulation material ETFE

Ordering Information:

Supplied as 100 m coil

Download Datasheet Technical specifications

This item is no longer available.

As an alternative, we recommend the following item:

ETFE-wire wrap switching wire, 7Y ETFE, 0.13 mm², AWG 26, black, outer Ø 0.91 mm, 370102609

Order No.: 91F8560

Manufacturer: Kabeltronik

per mtr. 0.6426 € *

*incl. VAT plus shipping costs

Description

Insulated wire-wrap hookup wires, type OK 100.

Compliant with VDE 0881

With 0.4 mm wire thickness, AWG 26, type 100-26.

Technical specifications

	Core insulation material	ETFE
	Outer diameter	0.71 mm
	AWG cross-section	AWG 26
	Colour	black
	Conductor category	CL.1 = stranded
	Cable material	copper, tin-plated
	Cable cross-section	0.13 mm²
	Rated voltage	375 V
	Test voltage	1.5 kV
	Temperature range (active)	-90 °C to 150 °C
