AST0450404 | METZ CONNECT
PCB terminal, 4 pole, pitch 5 mm, AWG 28-16, 12 A, spring-clamp connection, gray, AST0450404
Unit Price (€ / pc.)
2.3086 € *
Available: 194 pcs.
Leadtime: 11 Weeks **
Total Price:
2.31 € *
Price list
Quantity
Price per unit*
1 pcs.
2.3086 €
25 pcs.
1.9754 €
100 pcs.
1.8088 €
250 pcs.
1.7136 €
1000 pcs.
1.5589 €
*incl. VAT plus shipping costs
**Subject to prior sale
PCB terminal, AST0450404, METZ
It is suitable for solid wires and multi-stranded wires with a nominal cross section of 0.08 - 2.5 mm² and permits direct clamping without preconditioning of the conductor, direct clamping with splice protection and indirect clamping via an end sleeve or pin cable lug.
Features
- Spring clamp terminal block, solderable, double solder pins
- Direction of connection 45°
- Fittable without loss of poles
- Degree of protection: IP20
Technical specifications
| Anschluss | Federklemmanschluss | |
| AWG-Leiterquerschnitt | AWG 28-16 | |
| Farbe | grau | |
| Leiterquerschnitt | 0,08-1,0 mm² | |
| Nennspannung | 250 V | |
| Nennstrom | 12 A | |
| Polzahl | 4-polig | |
| Rastermaß | 5 mm |
Download
Logistics
| Ursprungsland | DE |
| Zolltarifnummer | 85369010 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
