ECAP100-33 | Mundorf
Bipolar electrolytic capacitor, 33 µF, 100 V (DC), ±5 %, axial, Ø 12 mm, ECAP100-33
Discontinued
Unit Price (€ / pc.)
4.3197 € *
Available: 23 pcs.
Leadtime: 17 Weeks **
Total Price:
4.32 € *
Price list
Quantity
Price per unit*
1 pcs.
4.3197 €
10 pcs.
3.7961 €
100 pcs.
3.3320 €
250 pcs.
3.2011 €
1000 pcs.
2.9869 €
*incl. VAT plus shipping costs
**Subject to prior sale
Bipolar electrolytic capacitor for high-end applications, type Mundorf ECAP.
Axial, aluminum oxide dielectric, films with surface roughened in a special etching process surface to increase the area; Capacitance tolerance: ±5.0 %. Operating temperatures: –40 to +85 °C. Useful life at +85 °C: 3000 h.
Rated voltage 35 VAC/100 VDC.
Technical attributes (type, capacitance, dimensions): ECAP100-33, 33 µF, 12 x 30 mm
Technical specifications
| Version | bipolar | |
| Design | axial | |
| diameter | 12 mm | |
| Capacity | 33 µF | |
| Length | 30 mm | |
| max. operating temperature | 85 °C | |
| min. operating temperature | -40 °C | |
| Rated voltage (AC) | 35 V | |
| Rated voltage (DC) | 100 V | |
| Tolerance | ±5 % |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85322200 |
| MSL | MSL 1 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
