00 6122 00 | Neosid
Suppressor choke, radial, 10 µH, 700 mA, 00 6122 00
Unit Price (€ / pc.)
1.8207 € *
Available: 104 pcs.
Leadtime: 13 Weeks **
Total Price:
1.82 € *
Price list
Quantity
Price per unit*
1 pcs.
1.8207 €
10 pcs.
1.1424 €
50 pcs.
0.9996 €
250 pcs.
0.8687 €
*incl. VAT plus shipping costs
**Subject to prior sale
Suppressor inductor, 00 6122 00, NEOSID
The 00 6122 00 is a fixed value choke inductor with or without a ferromagnetic core, used to block alternating current (AC) in a circuit by limiting the rate of change over a specified frequency range, while allowing passage of lower frequency AC or direct current (DC).
Features
- Solderability as per DIN IEC 68-2-20 Ta: 235°C, 5 sec.
Applications
- Decoupling of high and low frequency circuits
- Telecommunications
- Video equipment
- Electronic data processing systems
Technical specifications
| Version | suppressor choke | |
| Design | radial | |
| Width | 7.5 mm | |
| DC current | 700 mA | |
| DC resistance | 0.55 Ω | |
| Quality Q | Q 55 | |
| Height | 4.6 mm | |
| Inductance | 10 µH | |
| Length | 10.5 mm | |
| Measuring frequency | 38 MHz | |
| Tolerance | ±5 % |
Download
Logistics
| Country of origin | DE |
| Customs tariff number | 85045000 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
