00 7040 31 | Neosid

RFID-HF transponder NeoTAG Inlay, 40 mm, MF2626, for metallic environments

Order No.: 24M290
EAN: 4099879000279
MPN:
00 7040 31
Series: 00 704
00 7040 31 Neosid RFID Transponder
Image may differ
Unit Price (€ / pc.)
3.5700 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
3,570.00 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1000 pcs.
3.5700 €

With read/write function, for metallic environments.

Frequency range: 13.56 MHz

Simultaneous detection: of up to 50 transponders

Memory: EEPROM with 1024 bits, of which 896 bits with write attribute

Identification (UID): 64-bit. Access to the write enabled section can be protected with a password

Write cycles: approx. 100000

Data retention: approx. 50 years

Supported standard: ISO/IEC 15693 with anti-collision protection

Operating temperatures: - 20 to +85 °C

Type: NeoTAG Inlay MF2626, 40 mm

Technical specifications
Version RFID-HF-Transponder
nominal frequency 13.56 MHz
Memory size 1024 bit
Logistics
Country of origin DE
Customs tariff number 85235990
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
