NLT4MD-V | Neutrik
Speaker chassis plug, Lautsprechereinbaustecker, 4-polig, 250 V
Unit Price (€ / pc.)
6.1285 € *
Available: 0 pcs.
Leadtime: On Request **
Speaker chassis socket, series Speakon STX, type NEUTRIK NL.
metal male connector; particularly rugged and weatherproof (degree of protection: IP 54). Simple and precise quick-locking system. Contact finish: silver. Rated current: 40 A. Rated voltage: 250 VAC.Dielectric strength: 4.0 kVDC. Contact resistance: max. 2.0 mohm. Operating temperatures: - 30 to +80 °C. Certifications: UL, CSA.
Speaker chassis connectors, type NLT4.
With 3.5 mm connections for PCB mounting.
Type: NLT4MDV, speaker chassis connector
Technical specifications
| Version | plug | |
| Assembly | built-in mounting | |
| Rated voltage | 250 V | |
| Rated current | 50 A | |
| Pin number | 4 pole | |
| Type of locking | quick locking |
Download
Logistics
| Country of origin | LI |
| Customs tariff number | 85366990 |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
