NC3FAH1 | Neutrik

XLR panel socket, 3 pole, gold-plated, metal, NC3FAH1

Order No.: 70F1927
EAN: 4099889857924
MPN:
NC3FAH1
Series: A
NC3FAH1 Neutrik XLR Connectors
Image may differ
Unit Price (€ / pc.)
1.8564 € *
Available: 168 pcs.
Leadtime: 3 Weeks **
Total Price:
1.86 € *
Price list
Quantity
Price per unit*
1 pcs.
1.8564 €
25 pcs.
1.5589 €
100 pcs.
1.4399 €
250 pcs.
1.3685 €
1000 pcs.
1.2614 €
*incl. VAT plus shipping costs
**Subject to prior sale

XLR Connector, NC3FAH1, NEUTRIK

3 pole female XLR receptacle, grounding: mating connector shell to pin1 and front panel, horizontal PCB mount.

The `State of the Art` receptacle. Round plastic body XLR PCB mount panel connector. These have the smallest size and highest packing density (23mm between centres). New designed tulip type contacts with hard gold plating and polished contact areas.

FEATURES

  • Plastic housing, steel latch lock
  • Polished contact areas and hard gold plating
  • Smallest XLR receptacles, highest packing density

Technical Data

  • Version: Panel jack
  • Contact connection: Solder connection
  • Pin number: 3
  • Protection class: IP 40
  • Rated current: 6 A
Technical specifications
Version Einbaubuchse
Colour schwarz
Enclosure Metall
Contact connection Leiterplattenanschluss
contact surface vergoldet
Assembly Leiterplattenmontage
Rated voltage 50 V
Rated current 6 A
Pin number 3-polig
Type of locking Schnappverriegelung
Logistics
Country of origin LI
Customs tariff number 85366990
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
