NC3MXX-WT | Neutrik

XLR plug, 3 pole, silver-plated, 2.5 mm², AWG 14, NC3MXX-WT

Order No.: 70F1931
EAN: 4099889857962
MPN:
NC3MXX-WT
Series: XX
NC3MXX-WT Neutrik XLR Connectors
Image may differ
Unit Price (€ / pc.)
5.9857 € *
Available: 0 pcs.
Leadtime: 5 Weeks **
Total Price:
5.99 € *
*incl. VAT plus shipping costs
**Subject to prior sale
1 pcs.
5.9857 €

XLR Connector, NC3MXX-WT, NEUTRIK

3 pole male cable connector, white painted housing, silver contacts.

The next generation of the worldwide accepted standard of XLR cable connectors. The successor of the X series offers several new features which make it more reliable, easier to assemble and improves contact integrity as well cable strain relief.

FEATURES

  • Rugged zinc diecast shell, longlasting and dependable
  • Internal thread on shell is well protected against any damage
  • Boot with polyurethane gland gives high protection to cable bending stresses
  • Male connector with improved locking recess without "window", more stringent housing increases durability

Technical Data

  • Version: Plug
  • Contact connection: Solder connection
  • Pin number: 3
  • Protection class: IP 40
  • Rated current: 16 A
Technical specifications
Ausführung Stecker
AWG-Leiterquerschnitt AWG 14
Farbe weiß
Kabeldurchmesser 3,5-8 mm
Kontaktanschluss Lötanschluss
Kontaktoberfläche versilbert
Leiterquerschnitt 2,5 mm²
Montage Kabelmontage
Nennspannung 50 V
Nennstrom 16 A
Polzahl 3-polig
Verriegelung Schnappverriegelung
Logistics
Ursprungsland LI
Zolltarifnummer 85366990
Compliance
RoHS konform Yes
Stand der RoHS-Richtlinie 3/31/15
SVHC frei No
Substanz Beschreibung Blei
