BCV61B,215 | NEXPERIA
Bipolar junction transistor, NPN, 100 mA, 30 V, SMD, SOT-143, BCV61B,215
Unit Price (€ / pc.)
0.1416 € *
Available: 0 pcs.
Leadtime: On Request **
NPN transistor, BCV61B,215, NEXPERIA
NPN general-purpose double transistors in a small SOT143B surface-mounted device (SMD) plastic package.
Features
- Matched pairs
- AEC-Q101 qualified
Applications
- Applications with working point independent of temperature
- Current mirrors
Technical specifications
| Version | NPN | |
| Enclosure | SOT-143 | |
| max. operating temperature | 150 °C | |
| max.voltage between collector and base Vcbo | 30 V | |
| max.voltage between collector and emitter Vceo | 30 V | |
| min. operating temperature | -65 °C | |
| Assembly | SMD | |
| Saturation voltage | 250 mV | |
| Transit frequency fTmin | 250 MHz | |
| Collector current | 100 mA |
Download
Logistics
| Country of origin | MY |
| Customs tariff number | 85412900 |
Compliance
| RoHS conform | No |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
