S-1111A (P) | Nidec Copal
Encoding rotary switch, 16 pole, Hexadecimal-Real, angled, 100 mA/5 VDC, S-1111A (P)
Unit Price (€ / pc.)
4.5696 € *
Available: 29 pcs.
Next delivery: 25 pcs. on 2025-08-08
Leadtime: 22 Weeks **
Total Price:
4.57 € *
Price list
Quantity
Price per unit*
1 pcs.
4.5696 €
10 pcs.
4.0103 €
100 pcs.
3.5224 €
250 pcs.
3.3915 €
1000 pcs.
3.1773 €
*incl. VAT plus shipping costs
**Subject to prior sale
Rotary coding switches with adjustment shaft, type Copal S-1000A.
16 switch positions for hexadecimal code, for PCB connection; Contact and terminal material: gold-plated copper alloy. Contact rating: dynamic 100 mA/5.0 VDC, static 100 mA/50 VDC, minimum 1.0 µA/20 mV DC. Operating temperatures: –40 to +85 °C.
Side adjustment.
Type: S-1111A, hexadecimal real code
Technical specifications
| Anschluss | Leiterplattenstift | |
| Ausführung | Kodier-Drehschalter | |
| Bauform | abgewinkelt | |
| Betätigung | seitlich | |
| Kodierung | Hexadezimal-Real | |
| Kontaktoberfläche | vergoldet | |
| Polzahl | 16-polig | |
| Rastermaß | 2.54 mm | |
| Schaltleistung | 100 mA/5 VDC |
Download
Logistics
| Ursprungsland | CN |
| Zolltarifnummer | 85365080 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
