G5Q-14 12VDC | Omron

Name: Relay, 1 Form C (NO/NC), 12 V (DC), 360 Ω, 10 A, 30 V (DC), 277 V (AC), G5Q-14 12VDC
Brand: Omron
SKU: 29G8372
Price: 1.51 EUR
Availability: InStock

Relay, 1 Form C (NO/NC), 12 V (DC), 360 Ω, 10 A, 30 V (DC), 277 V (AC), G5Q-14 12VDC

Order No.: 29G8372

EAN: 4099889393170

MPN:

G5Q-14 12VDC

G5Q1412DC

Series: G5Q

Image may differ

Key Specification:

Contact type 1 Form C (NO/NC)

switching current 10 A

Coil voltage (DC) 12 V

Coil resistance 360 Ω

Download Datasheet Technical specifications

Unit Price (€ / pc.)

1.5113 € *

Available: 431 pcs.

Leadtime: On Request **

Total Price:

1.51 € *

Price list

Quantity

Price per unit*

1 pcs.

1.5113 €

25 pcs.

1.2852 €

100 pcs.

1.1900 €

250 pcs.

1.1305 €

1000 pcs.

1.0353 €

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Power relay, G5Q-14 12VDC, Omron

Features

Compact single pole relay
Excellent switching performance for a wide range of loads
Small, but with 8 kV pulse voltage (between coil and contacts)
Low coil power consumption (SPST-NO: 200 mW, SPDT: 400 mW)

Technical specifications

	Connection	PCB connection
	Contact type	1 Form C (NO/NC)
	Contact material	Ag alloy
	Switching Voltage (AC)	277 V
	Switching Voltage (DC)	30 V
	switching current	10 A
	Coil voltage (DC)	12 V
	Coil resistance	360 Ω
