LA G6SP-DAFA-24-1 | Osram Opto Semi
LED, SMD, amber, 625 nm, 4.5 to 14 cd, 120°, LA G6SP-DAFA-24-1
Unit Price (€ / pc.)
0.2939 € *
Available: 0 pcs.
Leadtime: On Request **
Advanced power LED, LA G6SP-DAFA-24-1, Osram Opto Semi
The LA G6SP-DAFA-24-1 is an advanced power top LED that features a compact package with a wide brightness range and high luminous efficiency.
Applications
- Custom tuning
- Interior illumination
- Signalling
Technical specifications
| Radiation angle | 120 ° | |
| Number of LEDs | 1 | |
| Width | 3 mm | |
| On-State Voltage | 2.15 V | |
| Forward Current | 200 mA | |
| Colour of the LED | amber | |
| Length | 3.3 mm | |
| Light intensity min. | 4.5 cd | |
| Light intensity typ. | 14 cd | |
| max. operating temperature | 100 °C | |
| min. operating temperature | -40 °C | |
| Assembly | SMD | |
| Wavelength | 625 nm |
Download
Logistics
| Customs tariff number | 85414100 |
| MSL | MSL 1 |
| Original Packaging | Reel with 1,000 pieces |
Compliance
| RoHS conform | Yes |
| Date of RoHS guidelines | 3/31/15 |
| SVHC free | Yes |
