ADY32024 | Panasonic
Relay, 1 Form A (N/O) + 1 Form B (N/C), 24 V (DC), 2880 Ω, 8 A, 30 V (DC), 250 V (AC), bistable, ADY32024
Unit Price (€ / pc.)
9.6628 € *
Available: 0 pcs.
Leadtime: 12 Weeks **
Power-Relay, ADY32024, Panasonic
Power-Relay, 1-Form-A, 1-Form-B, 2 coil latching
Features
- Latching types available
- Compliant with IEC EN61010-1
- Electrical life of Min. 2 105 times (1 Form A type) realized with inductive load (cos=0.4, L/R=7ms, 5A 250V AC)
Applications
- Control for industrial machines (machine tools, robotics)
- Output relays for temperature controllers, PLCs, timers, sensors.
- Measuring equipment
- Security equipment
Technical specifications
| Anschluss | Leiterplattenanschluss | |
| Kontaktart | 1 Schließer + 1 Öffner | |
| Kontaktmaterial | AgSnO2 | |
| Schaltspannung (AC) | 250 V | |
| Schaltspannung (DC) | 30 V | |
| Schaltstrom | 8 A | |
| Spulenspannung (DC) | 24 V | |
| Spulentyp | bistabil | |
| Spulenwiderstand | 2880 Ω |
Download
Logistics
| Ursprungsland | TH |
| Zolltarifnummer | 85364900 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
