TQ2-L2-4.5V | Panasonic
Relay, 2 Form C (NO/NC), 4.5 V (DC), 101.2 Ω, 1 A, 110 V (DC), 125 V (AC), TQ2-L2-4.5V
Unit Price (€ / pc.)
3.1416 € *
Available: 0 pcs.
Leadtime: On Request **
Total Price:
3.14 € *
Price list
Quantity
Price per unit*
50 pcs.
3.1416 €
100 pcs.
2.7846 €
500 pcs.
2.6180 €
1000 pcs.
2.4395 €
*incl. VAT plus shipping costs
**Subject to prior sale
Signal-Relay, TQ2-L2-4.5V, Panasonic
Signal-Relay, 2-Form-C, 2 coil latching, PC board
Features
- Suitable for SMD automatic insertion (SA type)
- High density mounting possible
- Low thermal electromotive force
Technical specifications
| Anschluss | Leiterplattenanschluss | |
| Kontaktart | 2 Wechsler | |
| Kontaktmaterial | Ag + Au | |
| Schaltspannung (AC) | 125 V | |
| Schaltspannung (DC) | 110 V | |
| Schaltstrom | 1 A | |
| Spulenspannung (DC) | 4.5 V | |
| Spulenwiderstand | 101.2 Ω |
Download
Logistics
| Ursprungsland | JP |
| Zolltarifnummer | 85364900 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
