TQ2SA-L-1,5V | Panasonic

Relay, 2 Form C (NO/NC), 1.5 V (DC), 32 Ω, 2 A, 110 V (DC), 125 V (AC), TQ2SA-L-1,5V

Order No.: 34G9498
EAN: 4099889410556
MPN:
TQ2SA-L-1,5V
TQ2SA-L-1.5V
Series: TQ2SA
Panasonic
TQ2SA-L-1,5V Panasonic Industrial Relays
Image may differ
Print
Key Specification:
Contact type 2 Form C (NO/NC)
switching current 2 A
Coil voltage (DC) 1.5 V
Coil resistance 32 Ω
Show 40 variants
Download Datasheet Technical specifications
Unit Price (€ / pc.)
3.2368 € *
Available: 0 pcs.
Leadtime: On Request **
Add to Cart
Total Price:
3.24 € *
*incl. VAT plus shipping costs
**Subject to prior sale
50 pcs.
3.2368 €
Description
Technical specifications
Download
Logistics
Compliance
Variations

Signal-Relay, TQ2SA-L-1,5V, Panasonic

Signal-Relay, 2-Form-C, 1 coil latching, SMD

Features

  • Suitable for SMD automatic insertion (SA type)
  • High density mounting possible
  • Low thermal electromotive force
Technical specifications
Connection SMD
Contact type 2 Form C (NO/NC)
Contact material AgNi + Au
Switching Voltage (AC) 125 V
Switching Voltage (DC) 110 V
switching current 2 A
Coil voltage (DC) 1.5 V
Coil resistance 32 Ω
Show similar products 0
Logistics
Country of origin JP
Customs tariff number 85364900
Compliance
RoHS conform Yes
Date of RoHS guidelines 3/31/15
SVHC free Yes
