NX5PRVM5A | Panasonic
Reflecting light barrier, 5 m, 12-240 VDC/24-240 VAC, cable connection, IP66, NX5PRVM5A
Micro photoelectric sensor, PM-K45-C3, PANASONIC
The PM-K45-C3 is as ultra-small U-shaped micro photoelectric sensor. This product features a through beam detection type with the emitter and receiver contained within a single U-shaped housing. A large operating indicator lights up to make operation identification easy to see from above and from the sides. The sections where stress concentrates, such as the connecting section of the cable and internal circuit are covered with a resin. This helps prevent malfunctions caused by vibrations and impacts
Connection | cable connection | |
Activation time | 10 ms | |
Version | reflecting light barrier | |
Detecting distance | 5 m | |
Switching logic | light ON | |
Degree of protection (IP) | IP66 | |
Voltage | 12-240 VDC/24-240 VAC |
Country of origin | CN |
Customs tariff number | 85365019 |
RoHS conform | Yes |
Date of RoHS guidelines | 3/31/15 |
SVHC free | Yes |
