AEQ11517 | Panasonic

Name: Ultraminiature snap-action switche, On-On, PCB connection, roller hinge lever, 1.7 N, 0.1 A/30 VDC, IP40, AEQ11517
Brand: Panasonic
SKU: 34G4740
Price: 3.84 EUR
Availability: OutOfStock

Ultraminiature snap-action switche, On-On, PCB connection, roller hinge lever, 1.7 N, 0.1 A/30 VDC, IP40, AEQ11517

Order No.: 34G4740

EAN: 4099889216660

MPN:

AEQ11517

Series: AEQ5

Image may differ

Key Specification:

Latching switching function On-On

Actuator roller hinge lever

actuating force 1.7 N

Switching point 9.3 mm ±0.5 mm

Connection PCB connection

Download Datasheet Technical specifications

Unit Price (€ / pc.)

3.8437 € *

Available: 0 pcs.

Leadtime: 12 Weeks **

Add to Cart

Total Price:

3.84 € *

*incl. VAT plus shipping costs

**Subject to prior sale

Description

Ultraminiature-Switch, AEQ11517, PANASONIC

Ultraminiature-Switch, Low level Load, IP40, 3 mm mounting hole, w/o boss type, PCB terminal type, SPDT, Leaf lever.

Features

Ultra-long stroke
Silent operation
Household appliances and air purifiers for safety purpose

Technical specifications

	Connection	PCB connection
	Design	straight
	Actuator	roller hinge lever
	actuating force	1.7 N
	Latching switching function	On-On
	Breaking capacity	0.1 A/30 VDC
	Switching point	9.3 mm ±0.5 mm
	Protection class	IP40
