Panel meter, PCE-BPD-C-66A, PCE Instruments

The panel meter is designed in such a way that the measured values ​​displayed can be read from a large distance. With a digit height of 60 mm or 100 mm, the reading distance for the panel meter is 25 m or 50 m. The red LEDs of the panel meter enable reading of the measured values ​​even in very bright surroundings. The housing of the panel meter is made of metal and is splash-proof with IP65. Thus, the panel meter can be used under harsh environmental conditions. Many different variants are available as input signals for panel meters. Among other things, the industry supports digital displays 4-20 mA and pulses. The panel meter is configured directly via the keypad. Digital display output interfaces are optionally available for industry.

This makes it possible to switch process signals and pulses via the panel meter when a limit value is reached, for example. The panel meter can be aligned vertically for optimal alignment when mounted on the wall. In addition to wall mounting, the panel meter can be mounted on a control cabinet. The insulation on the housing of the panel meter ensures that no water can get into the control cabinet.

Features

• Protection class IP65
• Robust metal housing
• Individually parameterizable
• Bright red LED indicator
• For wall or control cabinet mounting
• Different input signals
