1703771 | Phoenix Contact
Plug part, 2 pole, pitch 10.16 mm, 0.75-16 mm², AWG 18-6, straight, 76 A, 1000 V, screw connection, 1703771
Unit Price (€ / pc.)
9.6033 € *
Available: 0 pcs.
Available in 10 days: 40 pcs.
Leadtime: 1 Week **
Total Price:
9.60 € *
Price list
Quantity
Price per unit*
1 pcs.
9.6033 €
10 pcs.
8.8298 €
50 pcs.
8.0325 €
100 pcs.
7.2352 €
*incl. VAT plus shipping costs
**Subject to prior sale
Connecting Block, 1703771, Phoenix Contact
Feed-through connector, nominal current: 76 A, rated voltage (III/2): 1000 V, nominal cross section: 16 mm², number of positions: 2, pitch: 10.16 mm, connection method: Screw connection with tension sleeve, color: green, contact surface: Silver
FEATURES
- Well-known connection principle allows worldwide use
- Low temperature rise, thanks to maximum contact force
- Allows connection of two conductors
- Flange system enables secure fixing to the housing panel by means of tool-free snap-in locking or screws
Technical Data
- Rated current: 76 A
- Design: Straight
- Pole number: 4-pole
- Contact spacing: 10.16 mm
Technical specifications
| Ausführung | Buchse | |
| AWG-Leiterquerschnitt | AWG 18-6 | |
| Bauform | gerade | |
| Kontaktanschluss | Schraubanschluss | |
| Leiterquerschnitt | 0,75-16 mm² | |
| Nennspannung | 1000 V | |
| Nennstrom | 76 A | |
| Polzahl | 2-polig | |
| Rastermaß | 10.16 mm |
Download
Logistics
| Ursprungsland | PL |
| Zolltarifnummer | 85366990 |
Compliance
| RoHS konform | Yes |
| Stand der RoHS-Richtlinie | 3/31/15 |
| SVHC frei | Yes |
